PL BLOCK SNA 518_BF_1218 K

Short Description:- - PL Block SNA 518_BF_1218 K
Technical Specification:- - Bolt Dia:- - 18mm
Bore Dia:- 00160.000mm
Bore Width:- 00065.000mm
Brands:- Any Approved
Centre Height:- 00100.000mm
Hole Centre:- 280mm
No.Of Bolts:- 4
Plummer Block No:- PL Block SNA 518_BF
Shaft Dia:- 00080.000mm
Additional Specification:-
1. Plummer Block No. - SNA 518_BF Housing for Through shaft fixed end
2. Bearing No.- 1218 K
3. Hole center distance inmm ¿ 280
4. Centre height inmm - 100
5. Bore Diameter inmm - 160
6. Bore Width inmm - 65
7. Shaft Diameter - 80
8. Base Bolt Diameter inmm - 18
9. Halves Bolt Diameter inmm - 24
9. Make if any - Any approved
10. *Sealing type ¿ Labyrinth type
11. Locating Ring - Yes
12. Locating Ring size ¿ 17.5/160
# ALL PLUMMER BLOCKS COMPONENTS LIKE LABYRINTH RING, LOCATING RING, EN
D COVER ETC. SHALL BE FITTED/ASSEMBLED BEFORE DESPATCH
# PARTY HAS TO GET PRIOR APPROVAL OF THE RESPECTIVE DEPARTMENT BY SUBM
ITTING DRAWINGS FOR APPROVAL BEFORE GOING FOR MANUFACTURING
Custom Clarification:- -
Item Description
PL BLOCK SNA 518_BF_1218 K
Function of the Item
HOUSING FOR BEARING
Material of Construction of the Item
STEEL
Name of the Main Equipment where the Item is Used
BELT CONVEYOR
Function of the Main Equipment & Location of the Main Equipment
CONVEYING OF MATERIAL_COKE PLANT_KPO
